RAM Track CONTROL & POWER SUPPLY DEVICES

RAM Track control and power devices provide various unique features when used in conjunction with other RAM Track products as well as with accessories from other manufacturers.

RAM 59 RAIL POWERED 9 VOLT SOURCE.   See a photo of the RAM 59.
Designed to power RAM 9 volt lighting and sound systems, this device will work with AC or DC powered trains up to 28 volts. With an output in excess of 1 amp, it is both overload and short circuit protected. It must be connected to a power pick up truck for input from the rails. The size is 1" x 1-3/4  x 1-1/8" and a screw terminal strip is provided for simple installation.

RAM 60 ECONO REVERSING DEVICE.
This device optically controls the reversing action of a train on a single track. As supplied, end to end length can be up to 10 feet (can be extended) and the train can be delayed at each end for up to 45 seconds.

RAM 76 X TRA CONTROL.
Modelers are now able to turn on lights, sound horns, and operate a wide variety of accessories both onboard and trackside without the large investment in DCC systems. This accessory radio control system has a mini receiver (1" x 2-1/2" x 7/8") and a "key fob" transmitter that provide a range to 100 feet. The receiver provides BOTH a momentary and a latching control so that you can trigger one device, such as a whistle, for a specific time while leaving a second device, such as lights, turned on until you decide to turn it off. Each function can carry a load of 1 amp. There is provision to simply individualize each radio so that over 200 can be operated simultaneously without interference. The receiver requires 9 to 18V which can be supplied by a battery or rail power from a device such as the RAM 59. The transmitter comes with a replaceable battery.

RAM 85 STATION STOPPER.
This device stops a train and delays it for an adjustable time up to 1 minute before the train continues on. The circuit accommodates attachment of RAM Track digital sounds such as RAM 88 "All Aboard" or custom announcements. RAM 87 12 VOLT DC POWER REGULATOR. Provides a filtered, regulated, short circuit and thermally protected DC source to 1 1/2 amps from your train power pack's AC tap. It can be used to operate DC accessories on your railroad such as RAM Track Digital Sounds, Station Stopper and Structural Lights. Note that many "DC" train power packs NEED to be properly filtered to provide PURE DC.

RAM 87 12 VOLT DC POWER REGULATOR, FROM POWER PACK AC, UP TO 1.5 AMPS
Provides a filtered, regulated, short circuit and thermally protected DC source to 1 1/2 amps from your train power pack's AC tap. It can be used to opetate DC accessories on your railroad such as RAM Track Digital Sounds, Station Stopper and structural Lights. Note that many "DC"train power packs NEED to be properly filtered to provide PURE DC.


RAM 102 INFRA RED SWITCH.   See the RAM 102
This system uses infra red, eliminating magnets and minimum light requirements. It senses motion, such as a passing train, and switches devices up to 1/2 amp such as RAM digital sounds For convenient, trackside installation. the IR sender and receiver are each on 1 foot cables attached to the circuit board and powered by 5 to 24 volts D.C.

RAM 111 LIGHT ACTIVATED SWITCH.   See the RAM 111
A small photo cell senses a passing train and switches devices up to 1/2 amp such as RAM digital sounds. Light sensitivity is adjustable on the 1" x 1" circuit board powered by 5 to 24 volts DC

RAM 112 REED SWITCH AND MAGNET (3 sets).   New
A 1' reed switch is attached to 1' of wire to be triggered by a 5/16 high power, rare earth magnet.

RAM 113 TILT SWITCH.  New
This 1" cube is mounted in rotting stock to randomly trigger devices such as RAM digital sounds.

RAM 117 Dual Sensor Light Activated Switch.   New
All the same feature as the RAM 111 but has two small photo cells, perfect for activating a crossing signal or for similar needs. Two,  1/2 amp outputs can operate RAM 119 Crossing Lights and RAM 114 Crossing Bell or any similar device, 5-24V DC.
